Description
The 18″ Post Anchor is cast-in-place in concrete applications.
This permanent anchor can be used as a single point anchor or with a horizontal lifeline system.
Features:
- 18″ fixed steel anchor point
- Cast-in-place concrete installation
- Corrosion resistant galvanized coating
| Materials: | Galvanized steel |
| Weight: | 31 lbs. (14 kg) |
| Minimum Base Dimensions: | 13″ x 13″ (330 mm x 330 mm) |
| Breaking Strength: | 5,000 lbs. |
| ANSI Weight Capacity: | 130-310 lbs. (59-141 kg) |
| OSHA Weight Capacity: | Up to 420 lbs. (191 kg) |
| OSHA Standards: | 1926.502, 1910.140, 1910.66 |
