Description
Product Description
The PG 8 S is a powerful and robust planetary floor grinder with a focus on simplicity. This is a good choice for grinding and polishing jobs, and for users who prefer a non-motorised drive. Easy to use, the PG 8 S has a large capacity thanks to the 32 in / 800 mm grinding width and powerful motor. Adjustable weights for extra grinding pressure are optional.
The hermetically sealed design of the grinding head and electrical cabinet, along with the robustness of the components, contributes to high reliability and low maintenance.
Optional: Weights, water kit
Tool holder: EZchange™
Features
- Sealed to last
- Protected electronics
- Improved dust pick-up
- Ergonomic handle
- Time saving tool change
- Adjustable grinding pressure
- Fleet ready
- Quick release of tool holders
- EZchange™ Airflow tool holders
Tech Data Table
| Engine | ||
| Engine Power (As rated by the engine manufacturer) | 14.8 hp | 14.8 hp |
| Motor | ||
| Power source | Corded | Corded |
| Rated input power | 14.8 hp | 14.8 hp |
| Phases | 3 ph | 3 ph |
| Voltage | 200-240 V | 440-480 V |
| Rated current | 50 A | 30 A |
| Frequency | 50-60 Hz | 50-60 Hz |
| Pins | 3P+E | 3P+E |
| Equipment | ||
| Grinding width | 31.5 in | 31.5 in |
| Number of grinding discs | 3 | 3 |
| Direction of rotation | Both directions | Both directions |
| Grinding disc diameter | 9.1 in | 9.1 in |
| Grinding disc speed min | 420 rpm | 420 rpm |
| Grinding disc speed max | 1,176 rpm | 1,176 rpm |
| Transmission | ||
| Type of operation | Push | Push |
| Dimensions | ||
| Product size length | 54.6 in | 54.6 in |
| Product size width | 33 in | 33 in |
| Product size height | 44.7 in | 44.7 in |
| Weight | 1,120 lbs | 1,120 lbs |
| Packaging length (Calc) | 55.118 in | 55.118 in |
| Packaging width (Calc) | 35.433 in | 35.433 in |
| Packaging height (Calc) | 57.874 in | 57.874 in |
| Article gross weight (Calc) | 1,007.513 lbs | 1,007.513 lbs |
